OVERHEAD CONDUCTORS(AAC)

Code name	Nominal Aluminium Area	Equivalent copper area	Number & Diameter of All Wires		Overall Diameter of conductor	Nominal Braking Load	Max. DC Resistance at 20°C	Approx Weight	Current Rating
Code name	mm²	mm²	nos.	mm	mm	kgf	Ω / km	kg / km	Amps
MIDGE	22	14.2	7	2.06	6.18	408	1.227	64	114
APHIS	25	16.1	3	3.35	7.20	419	1.081	73	139
GNAT	25	16.1	7	2.21	6.60	468	1.068	74	124
WEEVIL	30	19.4	3	3.66	7.80	496	0.9082	87	144
MOSQUITO	35	22.6	7	2.59	7.80	617	0.7731	102	147
LADYBIRD	40	25.8	7	2.79	8.40	701	0.6694	118	159
ANT	50	32.3	7	3.10	9.30	846	0.5419	145	181
FLY	60	38.7	7	3.40	10.20	1010	0.4505	174	199
BLUEBOTTLE	70	45.2	7	3.66	11.00	1156	0.3884	203	219
EARWIG	75	48.4	7	3.78	11.40	1218	0.3645	216	227
GRASSHOPPER	80	51.6	7	3.91	11.70	1303	0.3405	232	238
CLEGG	90	58.1	7	4.17	12.50	1482	0.2994	264	256
WASP	100	64.5	7	4.39	13.20	1632	0.2702	292	271
BEE	125	80.6	7	4.90	14.70	2033	0.2169	364	308
CRICKET	150	96.8	7	5.36	16.10	2432	0.1814	436	342
